VCE5500C
VCE5500C – Powerful Three-Phase Dust Extractor for Demanding Applications
The Tyrolit VCE5500C is a high-performance three-phase dust extractor designed to handle the toughest tasks in the construction industry. With an optimal combination of high vacuum and large airflow, the VCE5500C ensures efficient dust extraction even under demanding conditions.
It is particularly well-suited for use with milling and grinding machines, floor saws, and shot blasting equipment. The filter cartridges are automatically cleaned using compressed air pulses, ensuring continuous operation and reducing the need for manual maintenance. For even more effective filtration, an optional HEPA filter system is available to capture fine dust particles and improve air quality.
Product description
-
High-performance three-phase dust extractor
-
Optimized combination of vacuum and airflow
-
Ideal for milling, grinding, sawing, and blasting applications
-
Automatic filter cleaning with compressed air pulses
-
Optional HEPA filter system for fine dust filtration
-
Designed for continuous operation in demanding environments
Technical specification
| Art.No.: | 11002933 |
| Voltage: | 400 V |
| Motor power: | 5,5 kW |
| Current: | 12,2 Amp |
| Max. airflow: | 38 m3/min |
| Hose: | Ø50 / 70 / 125 mm |
| Application: | Dry |
| Dimensions HxLxW: | 1560 x 1020 x 520 mm |
| Weight: | 220 kg |
| Frequency: | 50 Hz |
