Scan Dust 9000 World Series
Our largest and most efficient industrial dust extractor
The Scan Dust 9000 World Series is our largest and most efficient industrial dust collector, featuring increased filter capacity and built-in pre-separators. The unique and patented pre-separator separates the dust into two stages and provides up to 90% pre-separation. This means that you do not need to clean the filters as often, which provides a longer filter life and less interruptions for maintenance compared to traditional industrial dust extractors. Since the pre-separator is built into the machine, it is always included in the workplace, which means no extra equipment that needs to be handled or transported.
The filter area of the Scan Dust 9000 World Series is 4.2 m2 (45 sq/ft) and consists of 32 Teflon-coated sock filters and two Hepa 14 filters. Hepa 14 provides an extremely high filtration rate of 99.995% and takes care of the very smallest and most dangerous particles despite a very high air flow.
The electric version of the Scan Dust 9000 World Series is equipped with a frequency control drive which allows you to adjust the power and speed depending on the application. The combination of this, together with high filter capacity and high airflow, allows you to connect more machines to the same vacuum cleaner.
As with all machines in the World Series range, extra emphasis has been placed on design, ergonomics, and ease of service. The Scan Dust 9000 World Series has a height-adjustable cyclone for flexible transport options and is also equipped with solid rear wheels and 200 mm large swivel wheels for easy handling in the workplace.
The World Series design makes service simple, as you can easily access all parts and do not need to disassemble the machine to gain access.
The dust extractor is equipped with a filter guard that warns you when you need to clean the filters and a Jet-Pulse cleaning system that easily pulses the filters to keep them clean without having to come in contact with harmful dust. For simple and dust-free bag replacement, the proven Longopac bag system is incorporated into the Scan Dust 9000 World Series.
Scanmaskin always strives to increase sustainability and environmental consideration in our products and operations. The Scan Dust 9000 World series is no exception with steel construction and 95% recyclability.
Article number: 788501
Send request
Product description
- The whole machine is made of steel, and all covers are pressed in one piece, for better fitting.
- 3” / 76 mm Cam lock inlet with nylon bushed valve shutter
- Warning light with buzzer that alarms for a filter clean
- Hepa 14 filters
- Built-in pre-separator
- Longopac system Midi, holder pressed in steel
- High-quality vacuum pump
- Swivel wheels Ø200 mm
- Frequency drives for better control with high/ low speed and displayed pressure.
- Jet pulse
- 32 sock filters ptfe treated for superior lifetime
- Secondary pre-separation for longer working periods
Technical specification
| Electric version: | |
| Voltage: | 400-480 V 3~ |
| Motor Power: | 7,5 kW / 10 hp |
| Current: | 16 Amp |
| Max airflow: | 460 CFM / 782 m3/h |
| Max Vacuum: | 90 in / 225 mbar |
| Hose: | 33ft x 3” and 33ft x 2” / 10m x Ø76mm and 10m x Ø50mm |
| Inlet: | Ø3” Camlock / Ø76 mm |
| Primary filter: | 32 teflonated polyester sock filters, 4.2 m2 FT 99.5% |
| Micro filter: | Hepa 14, 2 x 3.9 m2 99.995% |
| Sound level: | 85 dB(A) |
| Dimension: | 59″x 29″x 74″/70″/62″ / 1500 x750 x 1990/1880/1590 mm |
| Height adjustments: | 74″/70″/62″ / 1990/1880/1590 mm |
| Weight: | 340 kg / 750 Ibs |
| Frequency: | 50 Hz/ 60 Hz |
| Filter cleansing: | Semi-automatic Jetpuls |
